Optimize your intermediate fluid manifolds and specialized pneumatic control loops with the authentic 26PCCFD6G board-level pressure sensor. This active piezoresistive component is factory-calibrated to deliver true wet/wet differential measurement across non-corrosive liquids and gases. Utilizing an advanced micromachined silicon Wheatstone bridge, it translates system pressures into an inherently linear, unamplified millivolt voltage for direct micro-controller calibration. The unique 1/4-28 UNF threaded port style ensures a secure, leak-free mechanical coupling to industrial fittings on the high-pressure side, while the traditional 1×4 SIP vertical layout provides excellent mechanical grounding on printed circuit boards.
Technical Specifications:
- Operating Pressure: 0 to 15 psi (differential reference)
- Signal Conditioning: Unamplified millivolt analog bridge
- Excitation Voltage: 10 VDC typical (up to 16 VDC maximum)
- Internal Seal Material: High-grade fluorosilicone elastomer
- Port Style: 1/4-28 UNF threaded port on P1 and straight axial on P2
- Termination Style: Through-hole PC pins (standard 4-pin SIP module)
- Compensated Range: 0°C to 50°C for exceptional zero-point tracking
- Operating Temperature: Verified stable from -40°C to +85°C
Common Engineering Applications:
- Medical respiratory equipment and chemical diagnostic monitors
- Liquid level tracking and flow monitoring in threaded manifold systems
- HVAC filter restriction indicators and medium-pressure process loops
