Optimize your low-range fluidic layouts and sensitive pneumatic control loops with the authentic 26PCBFB6G miniature pressure sensor. This active piezoresistive component is specifically calibrated to monitor low-pressure positive gauge pressure relative to localized ambient atmospheric conditions. Utilizing an advanced micromachined silicon Wheatstone bridge, it translates system pressures into an inherently linear, unamplified millivolt voltage for direct micro-controller calibration. The single barbed port ensures an exceptionally secure, slip-free mechanical coupling to flexible pneumatic tubing, while the traditional 4-SIP vertical package provides excellent mechanical grounding on printed circuit boards.
Technical Specifications:
- Operating Pressure: 0 to 5.0 psi (low range gauge reference)
- Signal Conditioning: Unamplified millivolt analog bridge
- Excitation Voltage: 10 VDC typical (up to 16 VDC maximum)
- Internal Seal Material: High-grade fluorosilicone elastomer
- Port Style: Single barbed axial configuration for secure tubing
- Termination Style: Through-hole PC pins (standard 4-pin SIP)
- Compensated Range: 0°C to 50°C for exceptional zero-point tracking
- Operating Temperature: Verified stable from -40°C to +85°C
Common Engineering Applications:
- Medical respiratory equipment and patient ventilation monitors
- Low-pressure industrial tank regulation and liquid level tracking
- HVAC filter restriction indicators and precise environmental sampling
